Products for
Automotive ADAS
Browse our products by end market and application. Each panel groups use cases by product, with a side-by-side specification comparison across manufacturers.
Automotive applications require long-range detection exceeding 200 meters, concentrated center-field resolution, reliable object classification at highway speeds, and strict adherence to functional safety standards. LiDAR plays a key role in supporting advanced driver assistance, highway automation, validation workflows, and autonomous vehicle perception.
Products
- HESAI: AT128, AT360, ATX, ETXP, OT128, PANDAR128
- ROBOSENSE: E1, EM4, EMX
- SEYOND: FALCON-K, ROBIN-E1X
| Sensor | Scan type | Vertical channels | Horizontal channels | FOV — horizontal | FOV — vertical | Range @10% | Minimum range | Accuracy | Weight | Power | Protection | Temperature range |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HESAIPandar128 | Mechanical | 128 | N/A (0.1° horiz. res.) | 360° | 40° | 200 m | 0.3 m | ±8 cm (0.3–0.5 m); ±5 cm (0.5–1 m); ±2 cm avg. (1–200 m) | 1.63 kg | 23–27 W | IP6K7 / IP6K9K | -40 °C to +85 °C |
| SEYONDFalcon K | Semi-solid-state | 152 | ≈2000 (derived @0.06°) | 120° | 25° | 250 m | 1.5 m | ±2 cm | 1.7 kg | 20 W | IP67 body / IP69K window | -40 °C to +85 °C |
| HESAIOT128 | Mechanical | 128 | N/A (0.1° horiz. res.) | 360° | 40° | 200 m | 0.3 m | ±3 cm (3–200 m) | 2.2 kg | 29 W | IP6K7 / IP6K9K | -40 °C to +75 °C |
| RoboSenseEMX | Solid state | 192 | up to 1750-eq | up to 140° | 25° | 150 m | 0.5 m | ±3 cm | 880 g | 16 W | IP68 | -40 °C to +85 °C |
| HESAIAT128 | Hybrid solid-state | 128 | 1200 | 120° | 25.4° | 210 m | 0.5 m | ±5 cm | 940 g | 13.5 W | IP6K7 / IP6K9K | -40 °C to +85 °C |
| RoboSenseE1 | Solid state | 144-eq | 192 | 120° | 90° | 30 m | 0.1 m | ±5 cm (1σ) | 330 ±20 g | <10 W | IP67 / IP6K9K | -40 °C to +85 °C |
| RoboSenseEM4 | Hybrid solid-state / 1D rotating mirror | 2160 | Up to 1900 | 120° | 27° | 300 m | 1 m | ±5 cm | <1000 g | 15 W | IP67 / IP6K9K | -40 °C to +85 °C |
| SEYONDRobin E1X | Solid state | 96 lines | 1200 | 120° | 20° | 200 m | 1 m | ±5 cm | 470 g | 6 W | IP67 body / IP69K window | -40 °C to +85 °C |
| HESAIAT360 | — | — | — | 120° | 18° | 300 m | — | — | — | — | IP6K7 / IP6K9K | — |
| HESAIATX | Hybrid solid-state | 256 | 1500 (derived @0.08°) | 120° | 20° | 230 m | Not published | Not published | 360 g | 8 W | IP6K7 / IP6K9K | -40 °C to +85 °C |
| HESAIETX | — | — | — | 120° | 20° | 400 m | — | — | 600 g | 11 W | IP6K7 / IP6K9K | — |
USE CASES
E1
Solid-state directional flash LiDAR with proprietary chips and a 120° × 90° ultra-wide field of view that scans the near-field blind spot in automotive, robotics and industrial automation applications requiring near-field detection for safety and access monitoring.
USE CASES
OT128
Scalable 360-Degree Perception
Calibration Free 360° Unstitched FOV
USE CASES
Pandar128
Auto-Grade 128-Channel 360°
High-Performance Long-Range Lidar
USE CASES
EMX
Real 192 beams, 300 m range and a 10 Hz frame rate in a 120 × 80 × 30 mm body.
USE CASES
Robin-E1X
Mid Range, compact, affordable solution for general purpose autonomy
USE CASES
EM4
The world’s first “thousand-beam” long-range digital LiDAR, delivering 2K high-definition 3D perception with 2160 beams, a 600 meter detection range and 41.04 million points per second for L3 and above autonomy.
USE CASES
USE CASES
ATX
Auto-Grade Compact 120°
High-Resolution Long-Range Lidar
USE CASES
Falcon-K
Wide FOV, compact, high resolution, blind spot detection, robotics, heavy equipment autonomy
USE CASES
AT360
Auto-Grade Compact 120°
High-Resolution Long-Range Lidar
USE CASES
ETXP
Automotive-Grade 120°
Ultra-High-Resolution Long-Range Lidar
