3D Lidar Sensors

	JT16	JT32	JT64P	JT128	FTX140/180	FT120	ATX	AT128	AT360	ETXP	XT16	XT32 XT32M1X	XT32M XT32m2X	QT128	OT128	Pandar128
Object Detection	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●	●
Mapping			●	●								●	●		●	●
Object Identification	●			●			●	●	●	●		●	●	●	●	●
Automotive Grade					●	●	●	●	●	●				●	●	●
Channels	16	32	64	128	192x256	120x160	256	128	360	1080/2160/4320	16/32	32	32	128	128	128
Field of View	360° X 40°	360° X 40°	360° X 189°	360° X 99°	140° X 105° / 180° X 140°	100° X 75°	140° x 20°	120° X 25.4°	18° X 120°	120° × 20°	360° X 31°	360° X 31°	360° X 40.3°	360° X 105.2°	360° X 40°	360° x 40°
Range	30m @ 10% Reflectivity	30m @ 10% Reflectivity	40m @ 10% Reflectivity	20m @ 10% Reflectivity	30m @ 10% Reflectivity	22m @ 10% Reflectivity	200 m @ 10% Reflectivity	210m @ 10% Reflectivity	250m	300 m @ 10% Reflectivity	80m @ 10% Reflectivity	80m @ 10% Reflectivity	80m @ 10% Reflectivity	20m @ 10% Reflectivity	200m @ 10% Reflectivity	200 m @10% Reflectivity
Min Range	0m	0m	0m	0m		0.1m		1m			0.05m	0.05m	0.5m	0.05m	0.3m	0.3m
Weight	0.199kg	0.199kg	0.22kg	0.22kg	0.2kg	0.7 kg	0.36 kg	0.94 kg	950g	0.6 kg	0.8 kg	0.8kg	0.49 kg	0.7 kg	2.2 kg	1.63 kg
Accuracy		3cm			5 cm	5 cm		5 cm	5cm		1 cm	1cm	1 cm	3 cm	3 cm	5cm
Max Range	100m	100m	25m	25m		50m	300m	260m	300m		120m	120m	300m	50m	230m	200m
Resolution Horizontal	0.6°	0.6°	0.4°	0.45°	0.56°	0.625°	0.08°	0.1° - 0.2°	0.06° - 0.12°	0.06°	0.09° - 0.36°	0.09° - 0.36°	0.09° - 0.36°	0.4° - 1.6°	0.1° - 0.4°	0.1°
Resolution Vertical	2.67°	1.29°	1.5°	0.8°	0.56°	0.625°	0.1°	0.2° - 0.8°	0.05° - 0.1°	0.055°	1°/ 2°	1°	1.3°	0.4° - 1.6°	0.125° - 1.72°	0.125°
Availability	Phasing Out	Taking Orders	Taking Orders	Now	Sampling Now. Production June 2026	Phasing Out	Now	Now	Now	Sampling Now. Production 2027	Now	Now	Now	Now	Now	Phasing Out

For our turnkey, off-the-shelf Handheld and Drone Mountable 3D Lidar Scanner Solutions Visit Our Scanner Store

FAQ

Does your price include shipping and tariffs?

The prices quoted are DAP and do include shipping, but do NOT include tariffs. If the sensor will be shipped to the US and you prefer DDP pricing (including tariffs), please contact our sales team at [email protected].

What is the lead time?

Hesai maintains a healthy stock of all their standard sensors (usually in the hundreds), so lead time is typically 2-3 weeks from receipt of order.

Do you offer volume discounts?

Yes! For larger orders, please contact our sales team at [email protected].

Do the sensors come with all cables needed?

The lidar sensors come with a connection box, a cable that connections the lidar to the connection box, and a power supply. You only need to supply an RJ45 ethernet cable to connect to the connection box.

Do you provide technical support?

Yes, both CRATUS and Hesai have technical support staff in the US and abroad to support our customers.

Is the connection box necessary for operation?

No, the connection box translates automotive ethernet to standard ethernet and provides a convenient power connection. Customers who want to directly integrate the lidar may do so.

Do Hesai sensors store or send any information?

Sensors do NOT contain any form of wifi or wireless communication method and it does NOT include a hard disk drive to store data.
